Specifications
MBF2H516B-EE[N/E]OTSpecifications
Physical
Form Factor: FHHL
Dimensions: 167.65mm x 11.15mm (6.6in. x 4.37in.)
Connector: Dual Ethernet QSFP56 (copper and optical)
Protocol
Support
InfiniBand: IBTA v1.3
a
Auto-Negotiation: 1X/2X/4X SDR (2.5Gb/s per lane), DDR (5Gb/s per lane), QDR (10Gb/s per lane), FDR10 (10.3125Gb/s per lane), FDR (14.0625Gb/s per lane), EDR (25Gb/s
per lane) port, HDR100 (2 lane x 50Gb/s per lane)
Ethernet: 100GBASE-CR4, 100GBASE-KR4, 100GBASE-SR4, 56GBASE-R4, 550G Ethernet Consortium, 40GBASE-CR4, 40GBASE-SR4, 40GBASE-LR4, 40GBASE-ER4, 25GBASE-CR/CR-
S, 25GBASE-SR, 25GBASE-LR, 25G Ethernet Consortium, 10GBASE-SR, 10GBASE-LR, 10GBASE-ER, 10GBASE-CX4, SGMII, 1000BASE-X
Data Rate
InfiniBand SDR/DDR/QDR/FDR/EDR/HDR100/HDR
Ethernet 1/10/25/40/50/100 Gb/s
PCI Express Gen 3.0 / 4.0: SERDES @ 8.0GT/s / 16GT/s, 16 lanes (2.0 and 1.1 compatible)
Power
Voltage: 12V
Maximum power available through QSFP56 port: 5W
Environment
al
Temperature Operational 0°C to 55°C
Non-operational
-40°C to 70°C
a
Ensure your system can support 75W or greater system power supply through the PCIe x16 interface and an additional 75W through the
supplementary 6-pin ATX power supply connector
