Chapter 16. Trusted Platform Module
Replacement
Caution: Static Sensitive Devices: Be sure to observe best practices for electrostatic discharge
(ESD) protection. This includes making sure personnel and equipment are connected to a common
ground, such as by wearing a wrist strap connected to the chassis ground, and placing components
on static-free work surfaces.
16.1. Trusted Platform Module Replacement
Overview
This is a high-level overview of the procedure to replace the trusted platform module (TPM) on the
DGX H100 system.
1. If enabled, disable drive encryption.
2. Shut down the system.
3. Label all motherboard tray cables and unplug them.
4. Slide out the motherboard tray.
5. Remove the tray lid and the DIMM air bae.
6. Lift the OSFP carrier module to access the TPM.
7. Replace the TPM on the motherboard.
8. Install the OSFP carrier module.
9. Install the DIMM air bae and motherboard tray lid.
10. Slide the motherboard tray into the system.
11. Plug in all cables using the labels as a reference.
12. Power on the system.
13. If the data drives need to be protected, then enable encryption.
97
