PCIe Compliance Testing Reference
PRELIMINARY INFORMATION
Jetson AGX Orin Series Tuning and Compliance Guide DA-11040-001_v0.7 | 15
Software
Use of official compliance test software is recommended, but not required. While manually
measuring the signal might be just as effective, it must ultimately pass with the compliance
software.
Table 5 contains a list of the recommended test software.
Table 5. Recommended Test Software
Company Product Image and Description
PCISIG Sigtest Sigtest post processing analysis tool
https://www.intel.com/content/www/us/en/design/technolo
gy/high-speed-
io/tools.html?grouping=rdc%20Content%20Types&sort=titl
e:asc
PCISIG Clock Jitter Tool Clock jitter tool
https://www.intel.com/content/www/us/en/design/technolo
gy/high-speed-
io/tools.html?grouping=rdc%20Content%20Types&sort=titl
e:asc
Test Equipment Vendor Scope, BERT software
and libraries
Capable Scope and BERT. Dedicated Test Software
Package for PCIe testing. See scope vendor for tailored
software packages.
Bitifeye N5990 software Optional software package
Example: https://www.bitifeye.com/download/
Also see: Keysight N5991 PCIe Test Automation Software
Platform
NVIDIA PATCH-A (mandatory) Patch to OS- PCIe driver to avoid PCIe controller power
down for Orin Tx testing for Orin as DUT. Use the patch for
the OS release being used. Open a BUG to track PATCH-A
release.
NVIDIA PATCH-B (mandatory
for Gen3 Sigtest)
Patch to OS- to disable Orin SSC on RefCLK. In some
cases, SSC for the Orin module RefCLK must be disabled
for Sigtest measurement. Use the proper patch for the OS
release being used.
Setup and Characterization
This section details the setup and characterization for the PCIe compliance testing.
DUT Setup
The DUT setup described here is based on the proprietary breakout board. The DUT setup
described hereinafter assumes the use of this breakout board and is an example of how test
To Next Page
