Jetson AGX Orin Series Tuning and Compliance Guide DA-11040-001_v0.7 | 40
"UnigrafDPTC." Refer to the test equipment documentation and dealer for more information
for the automation setup.
Objectives
Settings for drive strength and pre-emphasis must be found for the output configurations
described in Table 17 and Table 18.
DisplayPort
The tuned settings must work across all bit rates supported by the DUT: RBR, HBR, and HBR2
(optional), and HBR3 (optional).
Table 17. DisplayPort Configurations
Drive
Level
Pre-Emphasis
Level
Post
Cursor2
Drive
Level
Pre-Emphasis
Level
Post
Cursor2
400 mV 0.0 dB 0 600 mV 0.0 dB 0
400 mV 3.5 dB 0 600 mV 3.5 dB 0
400 mV 6.0 dB 0 600 mV 6.0dB 0
400 mV 9.5 dB 0
Drive
Level
Pre-Emphasis
Level
Post
Cursor2
Drive
Level
Pre-Emphasis
Level
Post
Cursor2
800 mV 0.0 dB 0 1,200 mV 0.0 dB 0
800 mV 3.5 dB 0
Embedded DisplayPort
The settings in Table 18 are required for fast link training. Since there is no specification for
the other bit rates or voltage levels, this guide will not cover them.
Table 18. Embedded DisplayPort Configurations
Bit Rate Drive Level Pre-Emphasis Level Post Cursor2 Level
RBR 400 mV 0.0 dB 0
HBR 400 mV 0.0 dB 0
HBR2 400 mV 0.0 dB 0
