Oki B4545 MFP User Manual

Maintenance
148
Miscellaneous incidents
At switch-on nothing appears on screen
Check that the power cable is plugged in, and check the power plug if
necessary.
The fax does not detect the presence of your inserted document. The
message READY does not appear on the screen.
At the start and during scanning, REMOVE DOCUMENT appears on the
screen.
Remove the document or press key .
Check the thickness of the document (50 sheets of paper of 80 g/m
2
).
Iron out the sheets if needed.
Help the sheets along.
The fax machine does not receive any faxes
Check that the telephone line cable is correctly plugged in and that there
is a tone signal on the telephone line by means of the key.
You receive a blank page
Make a photocopy of a document; if it is correct then your fax is
functioning normally. Call back the subscriber and have him resend the
document. It was probably sent with the sheet inserted backwards.
You cannot send a fax
Check that the telephone line cable is correctly plugged in.
Check the tone by pressing the key.
Check the prefix is correctly programmed and used.

Oki B4545 MFP Specifications

Printer

print speed	21 ppm
time to first page	13 seconds
print resolution	600 x 600 dpi
processor speed	92 MHz
duty cycle	12, 500 prints/copies per month

Fax

fax modem speed	33.6 Kbps
transmission speed	2.5 seconds
fax memory	500 pages (8 MB)

System Memory

standard imaging RAM	64 MB

Scanner

scan type	Color and Black & White
scan speed	1.8 sec./pg. Black & White; 16 sec./pg. Color
scan resolution	600 x 2400 dpi

Environmental

dimensions	17.9" x 17.5" x 20.5"
weight	32.0 lb. (14.5 kg)
power consumption	Operating 580W, Idle 20W, Power Save 15W
