Troubleshooting > 121
I
N
THE
PRINTER
SECTION
...
1. If a sheet is well advanced out of the top of the printer, simply grip it and pull gently
to draw it fully out. If it does not remove easily, do not use excessive force. It can be
removed from the rear later.
2. Lift the scanner.
3. Press the cover release (a) and open the printer’s top cover (b) fully.
4. Note the positions of the 4 cartridges.
It will be necessary to remove the four image drums to gain access to the paper path.
WARNING!
If the printer has been powered on, the fuser will be hot. This area
is clearly labelled. Do not touch.
1. Cyan cartridge 3. Yellow cartridge
2. Magenta cartridge 4. Black cartridge
a
b
