Troubleshooting > 36
6. If a paper fragment remains inside the printer:
(a) use forceps to grip and extract it or
(b) insert a triple folded sheet from the Paper Tray and turn the Platen Knob to pass
the folded sheet through and push out the paper fragment.
7. When the paper jams are cleared, close the printer Top Cover.
8. Set the Power Switch to ON.
C ONTINUOUS FORMS JAMMED IN PRINTER
1. Set the Power Switch to OFF.
2. Tear off any unprinted continuous forms.
3. Raise each Pin Tractor cover (1) and remove the continuous forms from the Pin
Tractor s.
4. Rotate the Platen Knob and remove the forms from the front or rear of the printer.
5. If a form fragment remains inside the printer, place two or three forms in a stack on
the Pin Tractors and turn the Platen Knob to push the fragment out of the printer.
6. Set the Power Switch to ON.
WARNING!
Do not carry out any operations inside the printer with the Power
Switch set to ON.
1

Oki ML6300FB-SC Specifications

General

Color	No
Character pitch	10, 12, 15, 17, 17.1, 20 cpi
Maximum resolution	360 x 360 DPI
Maximum printing width (columns)	-
Fonts included	Courier, Roman, Swiss, Prestige, Gothic, Utility, Swiss Bold, Orator, OCR-A, OCR-B, HSD & Barcodes
Print technology	Dot matrix
Connectivity technology	Wired
Page description languages	Epson ESC/P2, IBM ProPrinter
Sound pressure level (printing)	58 dB
Print direction	Bi-directional
Mean time between failures (MTBF)	12000 h
Paper feed	Manual
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Serial (RS-232)
Windows operating systems supported	Yes
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	30 - 85 %
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	255 mm
Width	425 mm
Height	210 mm
