Oki ML6300FB-SC User Manual

Specifications > 48
S PECIFICATIONS
ITEM SPECIFICATION
Model No. D21010B
Print method Impact dot matrix
Print head 24 pins, 0.2 mm (0.0079 in) diameter
Print direction Bi-directional, short-line-seeking printing,
Unidirectional printing
Print speed
High Speed Draft (HSD)
Letter Quality (LQ)
Utility
400cps @ 10 cpi
100 cps @ 10 cpi
300 cps @ 10 cpi
Line Feed (LF) time Approximately 65 ms per line for LF of 4.23 mm (1/6
in)
Form Feed (FF) speed Approximately 114.3 mm/s (4.5 in/s)
Paper feed control Paper feed: yes
Vertical tab: yes
Direct line feed: yes
Duplication capability Continuous forms: the original page +5 more pages
(total maximum paper thickness less than 0.36 mm)
Cut sheet: the original page +5 more pages (total
maximum paper thickness less than 0.36 mm)
Feeding direction Feed forward
Feed backward
Feeding mode Friction feed mode (front)
Push tractor feed mode (rear)
Continuous forms tape tail detection
method
Detected when remaining paper is approximately
6.35 mm long. It can, however, print till about
14.8 mm from the paper bottom (measured at the
centre of the characters).
(The print accuracy of the last page cannot be
guaranteed.)
Character sets Standard ASCII
Epson (Italics/Graphics)
Foreign
Code Page
Bar Code
Cut-sheet paper
Paper width
Paper length
Single-part Weight
Multipart Weight
Number of copies
Thickness
90 to 304.8 mm (3.54 to 12 in)
148 to 304.8 mm (5.82 to 12 in) (skew correction
mode)
55 to 420 mm (2.17 to 16.53 in)
52 to 209 gsm
64 to 209 gsm (skew correction mode)
40 gsm standard
Original plus 5 copies
0.36 mm (0.014 in) maximum

Oki ML6300FB-SC Specifications

General

Color	No
Character pitch	10, 12, 15, 17, 17.1, 20 cpi
Maximum resolution	360 x 360 DPI
Maximum printing width (columns)	-
Fonts included	Courier, Roman, Swiss, Prestige, Gothic, Utility, Swiss Bold, Orator, OCR-A, OCR-B, HSD & Barcodes
Print technology	Dot matrix
Connectivity technology	Wired
Page description languages	Epson ESC/P2, IBM ProPrinter
Sound pressure level (printing)	58 dB
Print direction	Bi-directional
Mean time between failures (MTBF)	12000 h
Paper feed	Manual
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Serial (RS-232)
Windows operating systems supported	Yes
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	30 - 85 %
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	255 mm
Width	425 mm
Height	210 mm
