Omron CP1E-ED User Manual

A-5
Appendices
CP1E CPU Unit Hardware User’s Manual(W479)
A-1 Dimensions
App
A-1-3 Expansion I/O Units
Unit: mm
Unit: mm
Unit: mm
A-1-3 Expansion I/O Units
CP1W-8ED Expansion I/O Unit with 8 Input Points
CP1W-8E Expansion I/O Units with 8 Output Points
CP1W-16E Expansion I/O Units with 16 Output Points
50
8
2 ‑ φ4.5
90 100±0.2
5
5
56±0.2
66
50
8
2 ‑ φ4.5
90 100±0.2
5
5
56±0.2
66
50
8
2 ‑ φ4.5
90 100±0.2
5
5
76±0.2
86

Omron CP1E-ED Specifications

General

Brand	Omron
Model	CP1E-ED
Category	Controller
Language	English
