1 Overview and Specifications
CP1E CPU Unit Hardware User’s Manual(W479)
1-3 Specifications
1
1-3-1 General Specifications
1-3 Specifications
The following table lists the general specifications of CP1E CPU Units.
*1 Total of 110 mm with mounting brackets.
*2 Excluding cables.
*3 Use the external power supply to power input devices. Do not use it to drive output devices.
*4 This is the rated value for the maximum system configuration. Use the following formula to calculate power consumption for CPU Units with DC power.
Formula: DC power consumption = (5V current consumption × 5 V/70% (internal power efficiency) + 24V current consumption) × 1.1(current fluctuation factor)
The above calculation results show that a DC power supply with a greater capacity is required.
1-3-1 General Specifications
Item AC power supply DC power supply
Model CP1E-D-A CP1E-D-D
Enclosure Mounted in a panel
Dimensions (H × D × W)
CPU Unit with 10 I/O points (CP1E-E10D-): 90mm
*1
×85mm
*2
× 66mm
CPU Unit with 14 or 20 I/O points (CP1E-14D-/20D-): 90mm
*1
×85mm
*2
× 86mm
CPU Unit with 30 I/O points (CP1E-30D-): 90mm
*1
× 85mm
*2
× 130mm
CPU Unit with 40 I/O points (CP1E-40D-): 90mm
*1
× 85mm
*2
× 150mm
CPU Unit with 60 I/O points (CP1E-N60D-): 90mm
*1
× 85mm
*2
× 195mm
CPU Unit with 20 I/O points and built-in analog (CP1E-NA20D-): 90mm
*1
× 85mm
*2
× 130mm
Weight CPU Unit with 10 I/O points (CP1E-E10D-): 300g max.
CPU Unit with 14 I/O points (CP1E-14D-): 360g max.
CPU Unit with 20 I/O points (CP1E-20D- ): 370g max.
CPU Unit with 30 I/O points (CP1E-30D- ): 600g max.
CPU Unit with 40 I/O points (CP1E-40D-): 660g max.
CPU Unit with 60 I/O points (CP1E-N60D-): 850g max.
CPU Unit with 20 I/O points and built-in analog (CP1E-NA20D- ): 680g max.
Electri-
cal spec-
ifications
Supply voltage 100 to 240 VAC 50/60 Hz 24 VDC
Operating voltage range 85 to 264 VAC 20.4 to 26.4 VDC
Power consumption 15 VA/100 VAC max.
25 VA/240 VAC max.
(CP1E-E10D-A/14D-A/
20D-A)
9W max. (CP1E-E10D-D)
13W max. (CP1E-N14D-D/N20D-D)
50 VA/100 VAC max.
70 VA/240 VAC max.
(CP1E-NA20D-A/30D-
A/40D-A/N60D-A)
20W max. (CP1E-NA20D-D/N30D-D/N40D-D/
N60D-D) *
4
Inrush current
120 VAC, 20 A for 8 ms max. for cold start at room temperature
240 VAC, 40 A for 8 ms max. for cold start at room temperature
24 VDC, 30A for 20 ms max. for cold start at room temperature
External power supply *
3
Not provided. (CP1E-E10D-A/14D-A/20D-A)
24 VDC, 300 mA (CP1E-NA20D-A/30D-A/
40D-A/N60D-A)
Not provided.
Insulation resistance 20 MΩ min. (at 500 VDC) between the external AC ter-
minals and GR terminals
Except between DC primary current and DC secondary
current
Dielectric strength 2,300 VAC 50/60Hz for 1 min between AC external and
GR terminals leakage current: 5 mA max.
Except between DC primary current and DC secondary
current
Power interrupt time 10 ms min. 2 ms min.
Applica-
tion envi-
ronment
Ambient operating temper-
ature
0 to 55°C
Ambient humidity 10% to 90%
Atmosphere No corrosive gas.
Ambient storage tempera-
ture
-20 to 75°C (excluding battery)
Altitude 2,000 m max.
Pollution degree 2 or less: Conforms to JIS B3502 and IEC 61131-2.
Noise resistance 2 kV on power supply line (Conforms to IEC61000-4-4.)
Overvoltage category Category II: Conforms to JIS B3502 and IEC 61131-2.
EMC immunity level Zone B
Vibration resistance Conforms to JIS 60068-2-6.
5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz
Acceleration of 9.8 m/s
2
for 100 min in X, Y, and Z directions (10 sweeps of 10 min each = 100 min total)
Shock resistance Conforms to JIS 60068-2-27.
147 m/s
2
, 3 times in X, Y, and Z directions
Terminal block Fixed (not removable)
Terminal screw size M3
Applicable standards Conforms to EC Directives.
Grounding method Ground to 100Ω or less.
