2-1 Specifications
2-1-1 General Specifications of CPU Units
Item CPU Units with
20 I/O points
CPU Units with
30 I/O points
CPU Units with
40 I/O points
CPU Units with
60 I/O points
Supply voltage
AC power 100 to 240 VAC, 50/60 Hz
pp y g
DC power 24 VDC
Operating
l
AC power 85 to 264 VAC
pg
voltage range
DC power 20.4 to 26.4 VDC
Power
i
AC power 60 VA max.
consumption
DC power 20 W max.
Inrush current
AC power 60 A max.
DC power 30 A max.
External power
l
Supply voltage 24 VDC
p
supply
(AC power
supplies only)
Output
capacity
300 mA: Use for input devices only. Cannot be used to drive outputs.
(When the external power supply provides an overcurrent or is short circuited, the
external power supply voltage will drop and PC operation will stop.)
(If 3 CPM1A-MAD11 Units are connected to the CPM2A-60CDR-A, then only a
maximum of 200 mA can be used from the external power supply.)
Insulation resistance 20 MΩ min. (at 500 VDC) between the external AC terminals and protective earth
terminals
Dielectric strength 2,300 VAC 50/60 Hz for 1 min between the external AC and protective earth
terminals, leakage current: 10 mA max.
Noise immunity Conforms to IEC6100-4-4; 2 kV (power lines)
Vibration resistance 10 to 57 Hz, 0.075-mm amplitude, 57 to 150 Hz, acceleration: 9.8 m/s
2
in X, Y, and Z
directions for 80 minutes each
(Time coefficient; 8 minutes × coefficient factor 10 = total time 80 minutes)
Shock resistance 147 m/s
2
three times each in X, Y, and Z directions
Ambient temperature Operating: 0° to 55°C
Storage: –20° to 75°C
Humidity 10% to 90% (with no condensation)
Atmosphere Must be free from corrosive gas
Terminal screw size M3
Power interrupt time AC power supply: 10 ms min.
DC power supply: 2 ms min.
(A power interruption occurs if power falls below 85% of the rated voltage for longer
than the power interrupt time.)
CPU Unit
ih
AC power 650 g max. 700 g max. 800 g max. 1,000 g max.
weight
DC power 550 g max. 600 g max. 700 g max. 900 g max.
Expansion I/O Unit weight Units with 20 I/O points: 300 g max.
Units with 8 output points: 250 g max.
Units with 8 input points: 200 g max.
Expansion Unit weight Analog I/O Units (MAD01): 150 g max.
Analog I/O Units (MAD11): 250 g max.
Temperature Sensor Units: 250 g max.
CompoBus/S I/O Link Units: 200 g max.
DeviceNet I/O Link Units: 200 g max.
Specifications Section 2-1
