Omron E5AN Communications Manual

Com Data
for Modbus
6.2 Status and status 2
6-19
■ Status 2 Structure
012345678910111213141516
0000
Bit position
Spare Outputs
Spare
OC (Heater Overcurrent) Alarm (CT1)
OC (Heater Overcurrent) Alarm (CT2)
Control Output 1 ON/OFF Count Alarm Output
Work bit 1
Work bit 2
Work bit 3
Work bit 4
Work bit 5
Work bit 6
Work bit 7
Work bit 8
Control Output 2 ON/OFF Count Alarm Output
Outputs
Bit position
16
0 0
171819202122232425262728293031 15
0 00000000000
Outputs
Spare
Invert direct/reverse operation
Spare
SP ramp
