Omron E5AN Communications Manual

CompoWay/F
2.3 Detailed Description of the Services
2-19
■ Operation Command
This service performs operations such as the following:
Service Request PDU
Service Response PDU
(1) Command Code and Related Information
• Communications
Writing
• RUN/STOP • Multi-SP
• AT Execute/Cancel • Write Mode • Save RAM Data
• Software Reset • Move to Setup Area 1 • Move to Protect Level
• Auto/Manual Switch • Parameter Initializa-
tion
• Alarm Latch Cancel
• Invert Direct/Reverse
Operation
•Program Start
Command
code
Command content Related Information
00 Communications Writing 00: OFF (disabled)
01: ON (enabled)
01 RUN/STOP 00: Run
01: Stop
02 Multi-SP 00: Set point 0
01: Set point 1
02: Set point 2
03: Set point 3
03 AT Execute/Cancel 00: AT cancel
01: 100% AT execute
02: 40% AT execute
04 Write Mode 00: Backup mode
01: RAM write mode
05 Save RAM Data 00
06 Software Reset 00
07 Move to Setup Area 1 00
08 Move to Protect Level 00
09 Auto/Manual Switch 00: Automatic mode
01: Manual mode
0B Parameter Initialization 00: Initialize to defaults
MRC SRC
3005
2222
Com-
mand
code
Related
informa-
tion
MRC SRC
3005
22 4
Response
code
