Omron E5AN Communications Manual

Com Data for CompoWay/F
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-2
3.1 Variable Area (Setting Range) List
For communications using a variable type not enclosed in parentheses in the following table, the set
value is double-word data (8 digits). For communications using a variable type enclosed in parentheses,
the set value is single-word data (4 digits).
For example, variable type C0 is double-word data (8 digits), and variable type 80 is single-word
data (4 digits).
Items expressed in hexadecimal in the “Set (monitor) value” column are the setting range for
CompoWay/F communications. The values in parentheses are the actual setting range. Use the values
in parentheses as the setting range for SYSWAY communications. When there is a section reference for
a setting item, refer to that reference for details.
Note 1: Not displayed on the Controller display.
Note 2: When the variable type is 80 (word access), the rightmost 16 bits are read.
Note 3: When the variable type is 80 (word access), the leftmost 16 bits are read.
Variable
type
Address Parameter name Setting (monitor) value Level
C0 (80) 0000 PV Temperature: Use the specified range for each sensor.
Analog: Scaling lower limit −5% FS to Scaling upper
limit +5% FS
Operation
C0 (80) 0001 Status (See notes 1 and 2.) See 3.2 Status and Status 2 for details.
C0 (80) 0002 Internal Set Point (See note
1.)
SP lower limit to SP upper limit
C0 (80) 0003 Heater Current 1 Value
Monitor
H'00000000 to H'00000226 (0.0 to 55.0)
C0 (80) 0004 MV Monitor (Heating) Standard: H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling: H'00000000 to H'0000041A (0.0
to 105.0)
C0 (80) 0005 MV Monitor (Cooling) H'00000000 to H'0000041A (0.0 to 105.0)
C0 (80) 0006 Heater Current 2 Value
Monitor
H'00000000 to H'00000226 (0.0 to 55.0)
C0 (80) 0007 Leakage Current 1 Monitor H'00000000 to H'00000226 (0.0 to 55.0)
C0 (80) 0008 Leakage Current 2 Monitor H'00000000 to H'00000226 (0.0 to 55.0)
C0 (80) 0009 Soak Time Remain H'00000000 to H'0000270F (0 to 9999)
C0 (80) 000C Multi-SP Monitor H'00000000 to H'00000003 (0 to 3)
C0 (80) 000E Decimal Point Monitor (See
note 1.)
H'00000000 to H'00000003 (0 to 3)
C0 (80) 000F Control Output 1 ON/OFF
Count Monitor
H'00000000 to H'0000270F (0 to 9999) Advanced
function
setting
C0 (80) 0010 Control Output 2 ON/OFF
Count Monitor
H'00000000 to H'0000270F (0 to 9999)
C0 (80) 0011 Status 2 (See notes 1 and
2.)
Refer to 3.2 Status and Status 2. Operation
C0 (80) 0012 Status (See notes 1 and 3.) Refer to 3.2 Status and Status 2.
C0 (80) 0013 Status 2 (See notes 1 and
3.)
Refer to 3.2 Status and Status 2.
