Omron E5AN Communications Manual

CompoWay/F
SECTION 2 CompoWay/F Communications Procedures
2-10
(5) Precautions
● Alarm Function
Even though alarms are not displayed on the Controller’s display, they
function normally in communications.
■ Write Variable Area
This service writes data to the variable area.
Service Request PDU
Service Response PDU
(1) Variable Type and Write Start Address
For details on variable types and write start addresses, see SECTION 3
Communications Data for CompoWay/F and SYSWAY.
(2) Bit Position
The E5CN/AN/EN/GN does not support bit access. Fixed to “00.”
1101 Area type error The variable type is wrong.
1103 Start address out-of-
range error
The read start address is out
of range.
110B Response too long The number of elements
exceeds the maximum.
1100 Parameter error Bit position is not “00.”
2203 Operation error EEPROM error
Response code Error name Cause
MRC SRC
0
222424
102 00
Variable
type
Start
write address
Bit
position
Number of
elements
Write Data (for
number of elements)
Number of elements
× 8 or 4
MRC SRC
0
22 4
102
Response
code
