A Appendices
A - 16
E5@C Digital Temperature Controllers User’s Manual (H174)
Meaning
Though this is not an error, it is displayed if the process value exceeds the display range when the
control range is larger than the display range.
The display ranges are shown below (with decimal points omitted).
• When less than −1,999: [[[[
• When more than 9,999: ]]]]
Operation
Control continues, allowing normal operation. The value will appear in the display for the PV.
Meaning
There is an error in internal circuits.
Action
First, turn the power OFF then back ON again. If the display remains the same, the Digital Controller
must be repaired. If the display is restored, then the probable cause is electrical noise affecting the
control system. Check for electrical noise.
Operation
The control, auxiliary, and transfer outputs turn OFF. (A linear current output will be approx. 0 mA. A
linear voltage output will be approx. 0 V.)
[[[[
]]]]
Display Range Exceeded
e333
AD Converter Error
−1999 9999
−
1999
9999
Resistance thermometer input (Except for models with a
setting range of −199.9 to 500.0°C)
Thermocouple input (Except for models with a setting range of
−199.9 to 400.0°C)
ES1B
Control range
s.err display
Numeric display s.err display
Input indication range
Analog Input
• When display range < control range
Control range
s.err display [[[[ display
Numeric display
Input indication range
]]]] display s.err display
Resistance thermometer input (Except for models with a
setting range of −1999. to 500.0°C)
Thermocouple input (Except for models with a setting range of
−199.9 to 400.0°C)
Control range
s.err display
[[[[ display
Numeric display
Input indication range
s.err display
Analog Input
• When display range ≥ control range
Control range
s.err display Numeric display s.err display
Display range*
*The display range is shown in numbers with decimal points omitted.
Input indication range
Display range*
To Next Page
