7-7
Explicit Messages Specific to DeviceNet-compatible Digital Indicators Section 5-3
Explicit Message Communications
5-3-1 Reading General Status
5-3-2 Writing Maintenance Mode Data
5-3-3 Setting and Monitoring the Digital Indicator Words
Explicit
message
Read/
write
Function Command Response
Service
code
Class
ID
Instance
ID
Attribute
ID
Data
size
General
Status
Read
Read Reads the DeviceNet-com-
patible Digital Indicator’s
general status bits (8 bits).
(Refer to page 6-5).
0E hex 95 hex 01 hex 65 hex --- 1 byte
Explicit
message
Read/
write
Function Command Response
Service
code
Class
ID
Instance
ID
Attribute
ID
Data
size
Mainte-
nance
Counter
Save
Save Records the maintenance
counter (PV of Unit con-
duction time for all Digital
Indicators) in memory.
16 hex 95 hex 01 hex 75 hex --- ---
Explicit
message
Read/
write
Function Command Response
Service
code
Class
ID
Instance
ID
Attribute
ID
Data size
Set Value
for Unit
Conduction
Time
Read Reads the set value
(monitor value) for the
Unit conduction time
(unit: 0.1 h (6 min)).
0E hex 7A hex 01 hex 68 hex 4 bytes
00000000 to
FFFFFFFF
hex (0 to
4294967295)
Write Writes the set value
(monitor value) for the
Unit conduction time
(unit:0.1 h (6 min)).
10 hex 7A hex 01 hex 68 hex 4 bytes
00000000
to
FFFFFFFF
hex (0 to
429496729
5)
Unit Con-
duction
Time Read
Read Reads the PV for the
Unit conduction time
(unit: 0.1 h (6 min)).
0E hex 7A hex 01 hex 66 hex 4 bytes
00000000 to
FFFFFFFF
hex (0 to
4294967295)
Monitor
Status of
Unit Con-
duction
Time Read
Read Reads the monitor sta-
tus for the Unit conduc-
tion time.
0E hex 7A hex 01 hex 67 hex 1 byte
00 hex: Within
range
01 hex: Out of
range (moni-
tor value
exceeded)
