Commands and Responses (CompoWay/F Communications) Section 1-9
CompoWay/F
Communications
1-9-4 Protect Level Setting Data Write
Command
This command writes protect level setting data.
This command is used in setting area 0. An error will result if used in setting
area 1.
To use this command, use the “Write via communications” operation com-
mand to enable “Write via communications,” and then use the “Move to pro-
tect level” operation command to move to “Protect level.”
Response
Response codes: The above indicates a normal end. For the response codes,
see 1-6 Writing to the Variable Area (page 1-10).
1-9-5 Setting Data Write (CompoWay/F Communications)
Command
The above setting data is written. The number of elements can be set from 2
to 24 to write setting data of contiguous addresses.
To specify an address, see SECTION 2 List of Settings (page 2-1).
Setting data of setting area 1 can be written in setting area 1. An error will
result if written in setting area 0.
To use this command, “Write via communications” must be enabled using the
“Write via communications” operation command.
Address Setting data
“0000” Operation adjustment protect
“0001” Setting level protect
“0002” Setting change protect
“0003” Forced zero protect
“0004” MAX/MIN protect
"01" "02" "C5" "00" "0001" Protect level setting data
Data
Number of
elements
Bit position
Address
Variable
type
SRCMRC
"01" "02" "0000"
Response code
SRCMRC
Variable type Address Setting data (explanation)
“C1”
“C2”
“0000” to “0004” Setting data of setting area 0
Protect level
RUN level
“C4”
“C5”
“C6”
“C7”
“C8”
“C9”
“CA”
“CB”
“0000” to “0027” Setting data of setting area 1
Initial setting level
Input adjustment level
Scaling level
Display adjustment level
Comparison setting
Linear output setting level
Communications setting level
Advanced function setting level
"01" "02" "00" "0001"
Data
Number of
elements
Bit position
Address
Variable
type
SRCMRC
Setting data
To Next Page
