6-6
I/O Allocation Section 4-2
Remote I/O Com-
munications
4-2-7 Operation Commands
Operation commands are used to for software resetting, to move to setting
area 1, and other similar operations. As shown in the following table, opera-
tion commands are executed using a combination of command codes, related
information, and strobes.
Operation commands for the K3HB-DRT are shown in the following table.
Note A software reset will not respond (no service PDU response).
Operation commands are created as shown in the following diagram.
Bit 15 is strobe 2 and bit 14 is strobe 1. A logical OR is taken between the two
leftmost bits of the command code and bits 15 and 14, and the result is
attached as the strobe to the operation command. The command code for
K3HB-DRT operation commands is 0@ hex, so when the logical OR is 8@
hex, the strobe is ON.
Resetting with an operation command is used for the following example.
Command
code
Details Related information
00 Communications write 00: OFF (Read only)
01: ON (Read/write)
01 Reset 00
02 Bank selection 00 to 07: Bank 0 to
bank 7
03 Zero execute/cancel 00: Zero cancel
01: Zero execute
06 Software reset 00
07 Move to Setting Area 1 00
08 Move to protect level 00
0B Initialize setting 00
0
15
Strobe
Command code
Upper byte
Related information
78
Strobe
Bit No.
Lower byte
Operation
command
1 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0
Strobe
Command code
01 Hex
Upper byte
F Hex 1 Hex
Related information
Strobe
Bit
8 1 F 1
Hex
078
15
Lower byte
Operation
command
