Omron K3HB-PPB User Manual

1-14
Commands and Responses (CompoWay/F Communications) Section 1-9
CompoWay/F
Communications
To specify the variable type or address, see SECTION 2 List of Settings
(page 2-1). The upper limit of an address will vary depending on the variable
type.
This command can be used in both setting area 0 and setting area 1.
Response
Response codes: The above indicates a normal end. For the response codes,
see 1-5 Reading the Variable Area (page 1-9).
1-9-3 Monitor Value/Setting Data Compound Read (CompoWay/F
Communications)
Command
Multiple monitor values or setting data can be read by sending a single com-
mand. Up to 20 items can be read even if the addresses are not contiguous.
To specify the variable type or address, see SECTION 2 List of Settings
(page 2-1). The upper limit of an address will vary depending on the variable
type.
This command can be used in both setting area 0 and setting area 1.
If an area type error or a setting data error occurs in any of the data being
read, no data will be read.
Response
Response codes: The above indicates a normal end. For the response codes,
see 1-5 Reading the Variable Area (page 1-9).
"01" "01"
"0000"
Setting data
Data
MRC SRC
Response code
Variable type Address Setting data (explanation)
“C0” “0000” to “0004” Monitor values
“C1” to “C2” “0000” to “0004” Setting data of setting area 0
“C4” to “CB” “0000” to “0027” Setting data of setting area 1
"01" "04" "00"
Bit positionAddress
MRC SRC
Variable
type
"00"
Bit position
Address
Variable
type
"00"
Bit position
AddressVariable type
"01" "04" "0000"
Type
Monitor value / Setting data
MRC SRC Response code Data
Type Monitor value / Setting data
Variable type Data
Variable
type
