1-6
1-5 Applicable Standards
1
Features and System Configuration
1-5 Applicable Standards
EC Directives
Note To conform to the EMC Directives, the Servomotor and Servo Drive must be installed under
the conditions described in 4-3 Wiring Conforming to EMC Directives.
UL/CSA Standards
The Servo Drives and Servomotors comply with UL 508C (file No. E179149) as long as the following
installation conditions 1 and 2 are met.
1. The Servo Drive must be used in a pollution degree 1 or 2 environment as defined in IEC 60664-
1 (example: installation in an IP54 control panel).
2. A UL-listed (with mark) circuit breaker or UL-listed (with mark) fuse must be connected
between the power supply and noise filter.
Refer to the following table for the rated current of the circuit breaker or fuse.
You must use copper wiring with a temperature rating of 60°C or higher.
Korean Radio Regulations (KC)
· SMARTSTEP2-series Servo Drives comply with the Korean Radio Regulations (KC).
· The G-series Servomotors do not comply with the Korean Radio Regulations (KC).
EC Directive Product Applicable standards Comments
Low Voltage
Directive
AC Servo Drive EN 61800-5-1 Safety requirements for electronic equipment for mea-
surement, control, or laboratory use
AC Servomotor IEC 60034-1 Rotating electric machines
EMC
Directive
AC Servo Drive EN 55011 class A
group1
Radio disturbance limits and measurement methods of
industrial, scientific, and medical radio-frequency
equipment
EN 61000-6-2 Electromagnetic compatibility (EMC): Immunity stan-
dard for industrial environments
Standard Product Applicable standards File number
UL Standard AC Servo Drive UL 508C E179149
AC Servomotor UL1004-1 E331224
CSA standard AC Servo Drive CSA C22.2 No. 14 E179149
AC Servomotor CSA C22.2 No. 100 E331224
Servo Drive model Rated current of circuit breaker (A)
R7D-BPA5L 5
R7D-BP01L 5
R7D-BP02L 5
R7D-BP01H 5
R7D-BP02H 5
R7D-BP02HH 5
R7D-BP04H 10
To Next Page
