6-3 Using the Parameter Unit
6
Operation
Auxiliary Function Mode
The Auxiliary Function Mode includes the alarm reset and jog operation.
Displaying Auxiliary Function Mode
Alarm Reset
1. Executing Alarm Reset
2. Returning to the Display of Auxiliary Function Mode
Key operation Display example Explanation
The items set for the Default Display (Pn01) is displayed.
Press the Data key to display Monitor Mode.
Press the Mode key four times to display Auxiliary Function Mode.
rk k k k k0k
Uknk_kskpkd.
fknk_kakckl.
Key operation Display example Explanation
Press the Data key to enter Alarm Reset Mode.
Press and hold the Increment key until “Start” is displayed.
The bar indicator will increase when the key is pressed for 5 s or longer.
The bar indicator will increase.
Alarm reset will start.
This display indicates a normal completion.
If is displayed, an alarm has not been reset. Reset the power
supply to clear the error.
akcklk k k-.
akcklk k-k-.
-k-k-k-k-k-.
sktkakrktk k
Key operation Display example Explanation
Press the Data key to return to the Auxiliary Function Mode Display.
fknk_kakckl.
