2-1 Standard Models
2
Standard Models and Dimensions
2Standard Models and Dimens ions
2-1 Standard Models
Servo Drives
Servomotors
 3,000-r/min Servomotors
Note Models with oil seals are also available.
Specifications Model
Single-phase 100 VAC 50 W R7D-BPA5L
100 W R7D-BP01L
200 W R7D-BP02L
Single-phase/three-phase
200 VAC
50 W
R7D-BP01H
100 W
400 W R7D-BP04H
Single-phase 200 VAC 200 W R7D-BP02HH
Three-phase 200 VAC 200 W R7D-BP02H
Specifications
Model
Straight shaft Straight shaft with key and tap
Without brake
100/200 V 50 W R88M-G05030H R88M-G05030H-S2
100 V 100 W R88M-G10030L R88M-G10030L-S2
200 W R88M-G20030L R88M-G20030L-S2
200 V 100 W R88M-G10030H R88M-G10030H-S2
200 W R88M-G20030H R88M-G20030H-S2
400 W R88M-G40030H R88M-G40030H-S2
With brake
100/200 V 50 W R88M-G05030H-B R88M-G05030H-BS2
100 V 100 W R88M-G10030L-B R88M-G10030L-BS2
200 W R88M-G20030L-B R88M-G20030L-BS2
200 V 100 W R88M-G10030H-B R88M-G10030H-BS2
200 W R88M-G20030H-B R88M-G20030H-BS2
400 W R88M-G40030H-B R88M-G40030H-BS2
