Omron SYSDRIVE 3G3JV Series User Manual

5-19
5-9 Multi-function I/O
5-9-1 Multi-function Input
The 3G3JV incorporates four multi-function input terminals (S2 through
S5).
Inputs into these terminals have a variety of functions according to the
application.
H Multi-function Input (n36 through n39)
n36 Multi-function Input 1 (S2) Changes during
operation
No
Setting
range
2 to 8, 10 to 22
(see note)
Unit of
setting
1 Default setting 2
n37 Multi-function Input 2 (S3) Changes during
operation
No
Setting
range
0, 2 to 8, 10 to 22
(see note)
Unit of
setting
1 Default setting 5
n38 Multi-function Input 3 (S4) Changes during
operation
No
Setting
range
2 to 8, 10 to 22
(see note)
Unit of
setting
1 Default setting 3
n39 Multi-function Input 4 (S5) Changes during
operation
No
Setting
range
2 to 8, 10 to 22, 34
(see note)
Unit of
setting
1 Default setting 6
Note Do not set values outside the above setting ranges.
Basic Operation Chapter 5
