20
EtherNet/IP Unit and Built-in EtherNet/IP Port Specifications Section 2-1
CJ2M-CPU3@
2-1-5 Software Configuration
76.16 mm
62 mm
2.7 mm
2.7 mm
90 mm
84.5 mm
75 mm
FINS
encapsulization
FINS Cyclic
Interface with CPU Unit
Memory Card/
EM file memory
FTP
Automatic
clock adjustment
FINSFINS
UDP
IP
ARP IGMP
LAN controller driver
LAN controller
Encapsulation
ICMP
TCP
FINS Service
(FINS/UDP and FINS/TCP)
CIP
Tag data link function Explicit messaging
