Macro Reference
380
Vision System FH/FZ5 Series
User’s Manual (Z340)
Color Data Approx. 1KB Approx. 25MB
Measurement region figure, selected region
figure of static mask, image size.
Gravity and Area Approx. 1KB Approx. 25MB
Measurement region figure, selected region
figure of static mask, image size.
Labeling
Approx.
2,000KB
Approx. 25MB
Measurement region figure, selected region
figure of static mask, image size.
Label Data Approx. 1KB No change -
Defect Approx. 1KB Approx. 51MB
Measurement region figure, selected region
figure of static mask, image size.
Precise Defect Approx. 20KB Approx. 29MB
Measurement region figure, detection
parameter settings, selected region figure of
static mask, image size.
Fine Matching Approx. 1KB
Approx. 38MB (for monochrome image)
Approx. 63MB (for color image)
Model registration figure, image size,
whether image is color or monochrome.
Character
inspection
Approx. 4KB No change -
Date Verification Approx. 1KB Approx. 1MB
Length of character string, code parameter
settings.
Model Dictionary Approx. 4KB
Approx. 95,567MB (for monochrome image)
Approx. 282,801MB (for color image)
Model registration count, model registration
figure, model parameters, image size,
whether image is color or monochrome.
2DCode Approx. 12KB Approx. 1MB
Length of comparison character string,
number and length of sorting comparison
character strings.
Barcode Approx. 3KB Approx. 1MB
Length of comparison character string,
number and length of sorting comparison
character strings.
OCR Approx. 704KB Approx. 1MB
Number and length of character string
formats, number and length of comparison
strings, number and length of teaching
correct response values, code parameter
settings.
OCR User
Dictionary
Approx. 1KB Approx. 1MB -
Circle Angle Approx. 1KB Approx. 1MB
Graduated angle, whether image is color or
monochrome.
Glue Bead
Inspection
Approx. 1KB Approx. 25MB
Measurement region figure, mask region
figure, image size.
Shape Search + Approx. 10KB No change -
Advanced labeling + Approx. 472KB No change -
Barcode + Approx. 6KB No change -
2DCode + Approx. 3KB No change -
Camera Image
Input
Approx. 1KB
Approx. 9MB (for monochrome image)
Approx. 17MB (for color image)
Model registration figure of calibration
settings, image size, whether image is color
or monochrome.
Camera Image
Input FH
Approx. 1KB
Approx. 9MB (for monochrome image)
Approx. 17MB (for color image)
Model registration figure of calibration
settings, image size, whether image is color
or monochrome.
Item
Approximate amount of application memory used
Main settings that affect change of
memory used
Adding to
measurement flow
Change due to settings
