Section 3 SETUP
ZFV
User’s Manual
Section 3
Setting Banks
Setting Banks
The ZFV Series can hold up to eight sets of settings. These settings can be switched
externally when changing the device setup
A set of these settings is called a “bank.”
Switching banks
BANK 1 is selected as the default. BANK 2 and 8 are also available.
MENU mode-[BANK]
Copying banks
Copy the settings of other bank numbers to an already selected bank number.
MENU Mode-[SYS1]-[BANKSET]-[COPY]
Clearing banks
“Clearing” deletes the settings of the currently selected bank number.
MENU Mode-[SYS1]-[BANKSET]-[CLEAR]
Setting the bank switching method
Select how to switch banks.
MENU Mode-[SYS1]-[BANKSET]-[SWITCH]
Setting Description
BANK 1~BANK 8
(default value: BANK 1)
Selects the target bank.
Setting Description
KEY (default value) Banks are switched by the control keys on Amplifier Unit.
I/O Banks are switched by the control keys on Amplifier Unit and input lead sig-
nals.
Switching by input lead signals is enabled only in the RUN mode.
BANKs can also be switched from an external device.
Setting the bank switching method p.60
[SYS1], [SYS2] settings and RUN Mode display settings cannot be cleared.
Header
