Section 4
APPENDIX
Section 4
Specifications and External Dimensions
83
ZFV
User’s Manual
Specifications and External Dimensions
Sensor Head
ZFV-SR10/SR50
33.6
30
(6.36)
30
(6.36)
4
20
32
4.5
4.5
67.9
17.9
5.6
32
12.8 dia.
4.5
4.5
20 0.1
2-M4
34
17.9
Mounting fixture can be attached on each side.
23.3
Mounting hole dimensions
Heat-resistant PVC shielded cable
5.8 mm dia. standard length 2 m
8.5
30.1
33
1/4-20 UNC depth 6
2-M4
depth 6
(Unit: mm)
