Onkyo A-DS650 User Manual

13
AC outlet connections
Connecting the power
•
Before you plug in the amplifier, confirm that all connections have been made properly.
• Before you turn on the power, make sure that the MASTER VOLUME control is fully turned counterclockwise.
•
Turning on this amplifier’s power may cause a momentary power surge, which might interfere with other electrical equipment, such as
computers. If this happens, use a wall outlet on a different circuit.
R
V
L
OUT
IN
VIDEO-1
OUT
IN
VIDEO-2
OUT
IN
OUT
IN
IN
IN
TAPE-1
TAPE-2
DVD
R
L
PHONO
CD
GND
R
L
R
L
R
L
R
L
FRONT
SPEAKERS
MAIN
CENTER
SPEAKER
SURROUND SPEAKERS
V
OUT
(REC)
IN
(PLAY)
OUT
(REC)
IN
(PLAY)
MONITOR
OUTPUT
SUBWOOFER
PRE OUT
FRONT REMOTE SPEAKERS
R
L
TUNER
FRONT
DIGITAL INPUT
DIGITAL 1
(OPTICAL)
DIGITAL 2
(COAXIAL)
OUT
IN
REMOTE CONTROL
SURROUND
CENTER SUBWOOFER
DIGITAL 3
(COAXIAL)
MULTI
CHANNEL
INPUT
L
R
R
L
CAUTION: SPEAKER IMPEDANCE
6 OHMS MIN. / SPEAKER
MODEL NO.
A-DS650
AC OUTLETS
SWITCHED
TOTAL 100W MAX.
50Hz
AC230V
Capacity is total
100 watts.
You can connect the power cord from other
audio device to the rear of the A-DS650.
Since the AC outlets on the unit are the
SWITCHED type, you can use the SYSTEM
button, or the POWER button on the remote
controller to turn on/off the power to both the
A-DS650 and the connected audio devices.
Note:If your A-DS650 has a POWER ( /
) switch, first turn it on.
The shape, number, and total capacity of the
AC outlets may differ depending on the area of
purchase. Make sure that the total capacity of
other components connected to this unit does
not exceed the capacity that is printed on the
rear panel.
ON
OFF
SYSTEM button
POWER switch
STAND-BY indicator
Display
To wall
outlet
DIGITAL AUDIO
SELECTOR
SMART SCAN CONTROLLER
ENTER
SURROUND
PARAMETER
3-D BASS
MAIN
REMOTE
SPEAKERS
REC OUT
MULTI SOURCE
Re-EQ
MIDNIGHT
THEATER
C DPHONOTUNERTAPE-2
MONITOR
TAPE-1
M D
VIDEO-2
VCR-2/TV
VIDEO-1
VCR-1
DVDINPUT
SELECTOR ®
MULTI-CH
INPUT
MASTER VOLUME
TREBLEBASS
AUDIO VIDEO CONTROL AMPLIFIER
A-DS650
MAXMIN
SYSTEM
POWER
ON
PHONES
STAND-BY
OFF
MULTIPLE SOURCE
REMOTE SYSTEM
HIGH DEFINITION
Re-EQ
TM
DOLBY SURROUND
PRO • LOGIC
1. Plug the power cord into an AC wall outlet.
2. Press the POWER switch to set the amplifier to
Standby mode.
The STAND-BY indicator will light up.
3. Press the SYSTEM button or POWER button on th
e
remote controller to turn on the amplifier. The dis-
play will light up and the STAND-BY indicator wil
l
be turned off.
If you press the SYSTEM button or POWER button on
the remote controller again, the amplifier returns to
Standby mode.
•
You cannot use the remote controller if the POWER
switch on the amplifier is set to OFF.
