31
Specifications
AMPLIFIER SECTION VIDEO SECTION
DIGITAL SECTION
GENERAL
REMOTE CONTROL (RC-374M)
Specifications and features are subject to change without notice.
Power Output
Continuous Power output
(DIN)
Front Main L/R channels: 100 W
×
2 at 6 ohms
Center channels: 100 W at 6 ohms
Surround L/R channels: 100 W × 2 at 6 ohms
Front Remote L/R channels: 100 W
×
2 at 6 ohms
Maximum Power output
(EIAJ)
Front Main L/R channels: 130 W
×
2 at 6 ohms
Center channels: 130 W at 6 ohms
Surround L/R channels: 130 W
×
2 at 6 ohms
Front Remote L/R channels: 130 W
×
2 at 6 ohms
IM Distortion: 0.08% at rated power (Front)
Damping Factor: 60 at 8 ohms (Front)
Input Sensitivity/Impedance
PHONO: 2.5 mV/50 kohms
CD/TAPE 1, 2/VIDEO-1, 2,
DVD, TUNER:
200 mV/50 kohms
MULTI CHANNEL INPUT
(FRONT L/R, SUR-
ROUND L/R, CENTER): 200 mV/50 kohms
MULTI CHANNEL INPUT
(SUBWOOFER): 36 mV/50 kohms
Output Level/Impedance
REC OUT: 200 mV/2.2 kohms
PRE OUT: 1 V/2.2 kohms
Phono Overload: 120 mV RMS at 1 kHz, 0.5% T.H.D.
Frequency Response: 20 Hz to 30 kHz, ±1 dB (Surround OFF)
RIAA Deviation: 20 Hz to 20 kHz, ±0.8 dB
Tone Control
Bass: ±10 dB at 50 Hz
Treble: ±10 dB at 10 kHz
Signal-to-Noise Ratio
(Surround OFF)
Phono: 80 dB (IHF A, 5 mV input)
CD/Tape: 100 dB (IHF A)
Muting: –∞ dB
Input Sensitivity and Imped-
ance
Video (Composite): 1 Vp-p/75 ohms
Output Level and Impedance
Video (Composite): 1 Vp-p/75 ohms
Digital input sampling fre-
quency:
32, 44.1, 48 kHz
Input sensitivity/impedance
Coaxial:
0.5 Vp-p/75 ohms
Power Supply
AC 230 V, 50 Hz
AC 220-230 V and 120 V switchable,
50/60 Hz
Power Consumption: 410 W
Dimensions (W
×
H
×
D): 435
×
175
×
390 mm
17-1/8"
×
6-7/8"
×
15-3/8"
Weight: 11.8 kg
12.5 kg
Transmitter: Infrared
Signal range: Approx. 5 meters, 16 ft.
Power supply: Two “AA” batteries (1.5 V
×
2)
