39
First Time Setup
—Continued
For TX-SR576
Note:
• This procedure can also be performed on the AV
receiver by using its [SETUP], [ENTER], and arrow
buttons.
If you connect a video component to an HDMI IN, you
must assign that input to an input selector. For example,
if you connect your DVD player to HDMI IN 1, you
must assign HDMI IN 1 to the DVD input selector.
By default, none of the HDMI inputs are assigned. The
following input selectors can be assigned: DVD,
VCR/DVR, CBL/SAT, AUX.
For TX-SR506
1
Press the [RECEIVER] button,
followed by the [SETUP] button.
2
Use the Up and Down [ ]/[ ]
buttons to select “2. Speaker
Setup,” and then press [ENTER].
3
Use the Up and Down [ ]/[ ]
buttons to select “2-1.Sp Set-
tings,” and then press [ENTER].
4
Use the Up and Down [ ]/[ ]
buttons to select “Impedance,”
and use the Left and Right [ ]/
[] buttons to select:
4 ohms:
Select if the impedance of any
speaker is 4 ohms or more but
less than 6.
6 ohms:
Select if the impedances of all
speakers are between 6 and
16 ohms.
5
Use the Up and Down [ ]/[ ]
buttons to select “Sp Type,” and
use the Left and Right [ ]/[ ]
buttons to select:
Normal:
Select this if you’ve con-
nected your front speakers
normally.
Bi-Amp:
Select this if you’ve con-
nected your front speakers for
bi-amped operation.
6
Press the [SETUP] button.
Setup closes.
HDMI Input Setup
1
Press the [RECEIVER] button,
followed by the [SETUP] button.
2
Use the Up and Down [ ]/[ ]
buttons to select “1.HDMI Input,”
and then press [ENTER].
3
Use the Up and Down [ ]/[ ]
buttons to select an input selec-
tor, and use the Left and Right
[ ]/[ ] buttons to select:
IN1:
Select if the video component
is connected to HDMI IN 1.
IN2:
Select if the video component
is connected to HDMI IN 2.
IN3:
Select if the video component
is connected to HDMI IN 3.
No:
Select if you’re not using the
HDMI OUT.
TX-SR506En.book Page 39 Friday, February 29, 2008 5:31 PM
