Table E-1 Gigabit Ethernet Cabling for Exalogic Machine Full Rack
From
Rack Slot
Type of Equipment From
Equipment
Port
To
Cisco
Switch
Port
Description
Not
applicable
External LAN NET 1 10' Blue Cat 5
Not
applicable
PDU-A NET 2 1M Grey Cat 5
Not
applicable
PDU-B NET 3 1M Grey Cat 5
U42 Compute node NET0 4 10' Blue Cat 5
U41 Compute node NET0 5 10' Blue Cat 5
U40 Compute node NET0 6 10' Blue Cat 5
U39 Compute node NET0 7 10' Blue Cat 5
U38 Compute node NET0 8 10' Blue Cat 5
U37 Compute node NET0 9 10' Blue Cat 5
U36 Compute node NET0 10 7' Blue Cat 5
U35 Compute node NET0 11 7' Blue Cat 5
U34 Compute node NET0 12 7' Blue Cat 5
U33 Compute node NET0 13 7' Blue Cat 5
U32 Compute node NET0 14 7' Blue Cat 5
U31 Compute node NET0 15 7' Blue Cat 5
U30 Compute node NET0 16 7' Blue Cat 5
U29 Compute node NET0 17 7' Blue Cat 5
U28 Compute node NET0 18 7' Blue Cat 5
U27 Compute node NET0 19 7' Blue Cat 5
U26 Sun Network QDR
InfiniBand Gateway Switch
NET0 38 7' Black Cat 5
U24 Sun Network QDR
InfiniBand Gateway Switch
NET0 39 7' Black Cat 5
U23 Sun Network QDR
InfiniBand Gateway Switch
NET0 40 7' Black Cat 5
U22 Storage appliance server head NET0 20 7' Blue Cat 5
U22 Storage appliance server head NET1 21 7' Blue Cat 5
Administrative Gigabit Ethernet Network-Cabling Tables
E-2 Oracle Exalogic Elastic Cloud Machine Owner's Guide
