• For KX-NT366/KX-NT553/KX-NT556/KX-NT560 users:
– When you answer an incoming call or when you seize an outside line, the display
automatically changes to the page that contains the green lit button.
– After customising each button, you can set the displayed text for the button. For details
about customising buttons, refer to "3.1.3 Customising the Buttons".
• For KX-UT248 and KX-UT670 users:
– You can customise the flexible buttons and set the displayed text for each button using
Web
Maintenance
Console. For details about customising buttons, refer to "Customising
the Flexible Buttons" in "
Editing Settings in Web Maintenance Console" in
"3.2.1 User Programming".
– For the KX-UT248, the display shows a maximum of 10 characters for each button. For
the KX-UT670, you can specify up to 12 characters, but some characters may not be
displayed depending on the characters used.
264 User Manual
1.14.4 Self Labelling (KX-NT366/KX-NT553/KX-NT556/KX-NT560/KX-UT248/KX-UT670 only)

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
