105
English
Using “Memory
viewer”
The “Memory viewer” selects still pictures and motion
pictures stored in a USB memory device, and show
them on the display.
Preparation
■ The files you can display with the “Memory
viewer”
The following files are supported.
Still pictures
Extension Format Limitation
jpg/
jpeg/
jpe
JPEG Number of pixels:
Minimum 32 x 32, Maximum
4 096 x 4 096
(supports baseline only)
YUV format: supports
YUV444, YUV442 and
YUV440
Colour mode:
supports RGB only
bmp Windows
Bitmap
Number of pixels: Minimum
32 x 32, Maximum 4 096
x 4 096
(1 bit, 4 bits, 8 bits, 24 bits)
Following formats are not
supported:
Run-length encoding, bit
field, top-down, transparent
data
If the number of pixels
exceeds 1 920 x 1 080, a
long time may be required
to display content.
Motion pictures
Extension Codec
Video Audio
avi H.264/MPEG4
AVC
AAC-LC/LPCM/MP/
WMA Standard
MPEG4 Visual
VC-1 Advanced
VC-1 Simple &
Main
mkv H.264/MPEG4
AVC
AAC-LC/HE-AAC/LPCM/
MP3
MPEG4 Visual
VC-1 Advanced
VC-1 Simple &
Main
H.265/HEVC
wmv asf H.264/MPEG4
AVC
LPCM/MP3/
WMA Standard/WMA9/
WMA10 Pro
MPEG4 Visual
VC-1 Advanced
VC-1 Simple &
Main
mp4/
mov/flv
H.264/MPEG4
AVC
AAC-LC/HE-AAC/MP3
MPEG4 Visual
H.265/HEVC
ts/mts H.264/MPEG4
AVC
AAC-LC/HE-AAC/LPCM/
MP3
H.265/HEVC
Limitation
Video
Codec Resolution
H.264/
MPEG4 AVC
MP@L5.1/
HP@L5.1
1 920 x 1 080p@60.0
3 840 x 2 160p@30.0
Bit rate: Maximum 80Mbps
•
MVC (Multi-view Video Coding) is
not supported.
H.265
MP@L5.1/
MP10@L5.1
3 840 x 2 160p@60.0
1 920 x 1 080p@60.0
Bit rate: Maximum 80Mbps
•
Only 1 warp-point GMC supported
•
Data Partitioning is not supported.
MPEG4
Visual
SP@L5/
ASP@L5
1 920 x 1 080p@30.0
Bit rate: Maximum 40Mbps
•
Video standard specified by MPEG4
Part2
VC-1
Advanced
AP@L3
1 920 x 1 080i@30.0
1 920 x 1 080p@24.0
Bit rate: Maximum 40Mbps
VC-1 Simple
& Main
SP@LL/SP@
ML/MP@LL/
MP@ML/
MP@HL
1 920 x 1 080p@30.0
Bit rate: Maximum 40Mbps
Audio
Codec Sampling
frequency (kHz)
Bit rate (kbps)
MP3 8/11.025/12/16/
22.05/24/32/44.1/
48
8 – 320
WMA
Standard
32 – 384
WMA 9 32 – 384
WMA 10 Pro 32 – 384
LPCM 64 – 1 536
Supported
quantization bit:
8/16/24/32
AAC(LC) 8 – 1 440
HE-AAC
(Ver.2 Level4)
8 – 256

Panasonic TH-65EQ1W Specifications

General

Response time	8 ms
Display diagonal	65 \
Display brightness	350 cd/m²
Display technology	VA
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Contrast ratio (dynamic)	50000:1
Contrast ratio (typical)	4000:1
Display number of colors	1.06 billion colors
Display diagonal (metric)	163.9 cm
Active display area (W x H)	1428 x 803 mm
DisplayPorts quantity	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
VGA (D-Sub) input ports	1
RMS rated power	20 W
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	13.5 mm
Placement supported	Indoor
Bezel width (bottom)	14.5 mm
Panel mounting interface	400 x 400 mm
Purpose	Universal
HDCP version	2.2
Operating hours (hours/days)	18/7
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	185 W
Package depth	280 mm
Package width	1655 mm
Package height	1078 mm
Package weight	38000 g
Cables included	AC
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	82 mm
Width	1459 mm
Height	835 mm
Weight	27000 g
