Panasonic TH-65EQ1W User Manual

8
English
Safety Precautions
WARNING
■ Setup
This LCD Display is for use only with the following
optional accessories.
Use with any other type of optional accessories may
cause instability which could result in the possibility
of injury.
Securely install the pedestal and wall hanging
bracket of the optional accessories. Ask an
authorized dealer for installation.
The following number of people are required for
installation.
86-inch model
75-inch model
: 4 or more
65-inch model
55-inch model
50-inch model
43-inch model
: 2 or more
•
Pedestal
75-inch model
: TY-ST75PE9
65-inch model
: TY-ST55PE9
55-inch model
50-inch model
43-inch model
:
TY-ST43PE8
•
Wall hanging bracket
*
1
86-inch model
75-inch model
:
TY-WK98PV1
•
Early Warning Software
(Basic license/3-year license):
ET-SWA100 series
*
2
*
1: This product can be purchased in the U.S. and
Japan.
*
2: Suffix of the part number may differ depending on
the license type.
Note
●
The part number of the optional accessories are
subject to change without notice.
When installing the pedestal or wall hanging bracket,
read the operating instructions supplied with it carefully
and install properly. Also, always use the overturn
prevention accessories.
We are not responsible for any product damage, etc.
caused by failures in the installation environment for
the pedestal or wall hanging bracket even during the
warranty period.
Small parts can present choking hazard if accidentally
swallowed. Keep small parts away from young children.
Discard unneeded small parts and other objects,
including packaging materials and plastic bags/sheets to
prevent them from being played with by young children,
creating the potential risk of suffocation.
Do not place the Display on sloped or unstable
surfaces, and ensure that the Display does not hang
over the edge of the base.
•
The Display may fall off or tip over.
Install this unit at a location with minimal vibration
and which can support the weight of the unit.
•
Dropping or falling of the unit may cause injury or
malfunction.
Caution - For use only with UL Listed Wall Mount
Bracket with minimum weight/load 66.0
(145.5 lbs).
When installing the display vertically, be sure that
the power indicator comes to the right side.
Power indicator
43-inch model
Power indicator
75-inch model
65-inch model
55-inch model
50-inch model
Power indicator
86-inch model
•
If installed in different directions, heat is generated
and it may cause fire or damage to the Display.
Cautions for Wall or Pedestal Installation
•
The installation should be performed by an installation
professional. Installing the Display incorrectly may
lead to an accident that results in death or serious
injury. Use the optional Pedestal. (see page 8)
•
When installing on a wall, the specified wall hanging
bracket (optional accessory) or a wall hanging bracket
that conforms to VESA standards must be used.
86-inch model
75-inch model
: VESA 600 × 400
65-inch model
50-inch model
: VESA 400 × 400
55-inch model
: VESA 400 × 200
43-inch model
: VESA 200 × 200
(see page 11)
•
Before installation, be sure to check if the mounting
location has enough strength to support the weight of
the display and the wall hanging bracket for anti drop.
•
If you terminate the use of the product, ask a
professional to remove it promptly.
•
When mounting the Display on the wall, prevent the
mounting screws and power cable from contacting
metal objects inside the wall. An electric shock may
occur if they contact metal objects inside the wall.

Panasonic TH-65EQ1W Specifications

General

Response time	8 ms
Display diagonal	65 \
Display brightness	350 cd/m²
Display technology	VA
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Contrast ratio (dynamic)	50000:1
Contrast ratio (typical)	4000:1
Display number of colors	1.06 billion colors
Display diagonal (metric)	163.9 cm
Active display area (W x H)	1428 x 803 mm
DisplayPorts quantity	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
VGA (D-Sub) input ports	1
RMS rated power	20 W
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	13.5 mm
Placement supported	Indoor
Bezel width (bottom)	14.5 mm
Panel mounting interface	400 x 400 mm
Purpose	Universal
HDCP version	2.2
Operating hours (hours/days)	18/7
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	185 W
Package depth	280 mm
Package width	1655 mm
Package height	1078 mm
Package weight	38000 g
Cables included	AC
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	82 mm
Width	1459 mm
Height	835 mm
Weight	27000 g
