PJLink protocol
The unit’s Network function is compatible with PJLink
Class 1. The following operations can be performed from
a computer when PJLink protocol is used.
●
Setting the Display
●
Querying the Display status
Supported commands
The commands to control the unit with PJLink protocol
are as follows.
Command Control
POWR Power control
0: Standby
1: Power On
POWR? Power status query
0: Standby
1: Power On
INPT Input switch
11: PC IN input (PC / PC[YP
BPR])
21: AV IN input (VIDEO)
31: HDMI 1 input (HDMI1)
32: HDMI 2 input (HDMI2)
33: DVI-D IN input (DVI-D)
41: USB input (USB)
42: MEMORY VIEWER input
(MEMORY VIEWER)
INPT? Input switch query
11: PC IN input (PC / PC[YP
BPR])
21: AV IN input (VIDEO)
31: HDMI 1 input (HDMI1)
32: HDMI 2 input (HDMI2)
33: DVI-D IN input (DVI-D)
41: USB input (USB)
42: MEMORY VIEWER input
(MEMORY VIEWER)
AVMT Shutter control
10: Picture On
(picture mute deactivated)
11: Picture Off
(picture on mute)
20: Audio On
(audio mute deactivated)
21: Audio Off
(audio on mute)
30: Shutter mode Off
(picture and audio mute
deactivated)
31: Shutter mode On
(picture and audio on mute)
Command Control
AVMT? Shutter control query
11: Picture Off (picture on mute)
21: Audio Off (audio on mute)
30: Shutter mode Off
(picture and audio mute
deactivated)
31: Shutter mode On
(picture and audio on mute)
ERST? Error status query
First byte: 0
Second byte: 0
Third byte: 0
Fourth byte: 0
Fifth byte: 0
Sixth byte: Other error. 0 or 2.
●
Meaning of 0, 2.
0: Error is not detected,
2: Error
LAMP? Lamp status query
Not supported
INST? Input switch list query
11: PC IN input (PC / PC[YP
BPR]))
21: AV IN input (VIDEO)
31: HDMI 1 input (HDMI1)
32: HDMI 2 input (HDMI2)
33: DVI-D IN input (DVI-D)
41: USB input (USB)
42: MEMORY VIEWER input
(MEMORY VIEWER)
NAME? Display name query
The name selected in [Display name]
is returned.
INF1? Manufacturer name query
Returns “Panasonic”.
INF2? Model name query
Returns “55EQ1U” / “55EQ1W”.
(Example: 55-inch EQ1U / EQ1W
model)
INFO? Other information query
Returns version number.
CLSS? Class information query
Returns “1”.

Panasonic TH-65EQ1W Specifications

General

Response time	8 ms
Display diagonal	65 \
Display brightness	350 cd/m²
Display technology	VA
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Contrast ratio (dynamic)	50000:1
Contrast ratio (typical)	4000:1
Display number of colors	1.06 billion colors
Display diagonal (metric)	163.9 cm
Active display area (W x H)	1428 x 803 mm
DisplayPorts quantity	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
VGA (D-Sub) input ports	1
RMS rated power	20 W
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	13.5 mm
Placement supported	Indoor
Bezel width (bottom)	14.5 mm
Panel mounting interface	400 x 400 mm
Purpose	Universal
HDCP version	2.2
Operating hours (hours/days)	18/7
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	185 W
Package depth	280 mm
Package width	1655 mm
Package height	1078 mm
Package weight	38000 g
Cables included	AC
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	82 mm
Width	1459 mm
Height	835 mm
Weight	27000 g
