Panasonic Toughbook CF-19CHBAXBM User Manual

9-19
9.2.6. Setting the Display Unit
1. Fix the Display Unit using the 2 Screws <N9>.
2. Close the Display Unit and turn the computer over, then
fix the Display Unit using the 4 Screws <N18>.
3. Turn the computer over and fix the LCD Hinge Cover
using the 2 Screws <N1>.
4. Open the Display Unit and fix the LCD Hinge Cover using
the 2 Screws <N1>.
Screws <N1> : DFHE5025XA
Screws <N9> : DRSB2+5FKL
Screws <N18> : XYN4+J7FNL
<N18>
<N18>
<N18>
<N18>
<N9>
<N9>
Hinge Cover
<N1>
<N1>
LCD Hinge Cover
<N1>
<N1>
