Panasonic Toughbook CF-19CHBAXBM User Manual

11 Replacement Parts List
CF-19CHBAXBM (2006/12/06)
PART NO. DESCRIPTION Q'TY
E1 DL3U11530AAA
PCB,MAIN
RTL 1
E2 DL3U21530AAA
PCB,AUDIO
RTL 1
E3 DL3U31530AAA
PCB,IO
RTL 1
E4 DL3U11550BAA
PCB,PAD
RTL 1
E5 DL3U21550BAA PCB,SW RTL 1
E6 DL3U31550BAA PCB,LED‑LEFT RTL 1
E7 DL3U41550BAA
PCB,PR
RTL 1
E8 DL3U61550BAA
PCB,LED‑RIGHT
RTL 1
E9 DL3U71550BAA
PCB,SD
RTL 1
E10 DL3U81550BAA
PCB,HSDPA
RTL 1
E11 DL3U91550BAA
PCB,POWERSW
RTL 1
E12 DL3UP1552AAA
PCB,EXTANTUNIT
RTL 1
E13 DL3UP1558BAA
PCB,BT2.0UNIT
RTL 1
E14 DL3UP1566AAA
BATFPCUNIT
1
E15 DL3U11553AAA
WWANMAINANT
1
E16 DL3U21553AAA
WWANAUXANT
1
E17 DL3U31553AAA
LAN‑MAINBTANT
1
E18 DL3U41553AAA
LANAUXANT
1
E19 DL3U11605AAA
CF‑19TSPCB
1
E20 DFJS1060ZA WWANCOAXIALCABLE 1
E21 DFJS1039YA
LCDCABLETS
1
E22 S N0GB1J000018
INVERTER
1
E23 S N3CAYYY00012
HDD
1
E24 N2ABAJ000001 KEYBOARDUS 1
E25 DFJS1061ZA MODEMJACKCABLE 1
E26 S N5HAZ0000014 MODEM 1
E27 N5ZZ00000119 PC2‑4200SODIMM512MINFINEON 1
E28
DFJS1059ZA WLANCOAXIALCABLE
1
E29 S N5HZC0000019
WIRELESSLANMODULE
1
E30 D4CZY103A003
THERMISTOR
1
E31 DFJS1043ZA
POWERSWCABLE
1
E32 N2EABEC00006
TOUCHPAD
1
E33 BR‑2330A/SF
LITHIUMCOINBATTERY
1
E34 DFJS1062ZB
LANJACKCABLE
1
E35 K1NB94B00001
EXPRESSPCMCIACOMBOSLOT
1
E36 DFWV08A0089
LCD UNIT ASS'Y
1
E36‑1 DL3DW0182AAA LCDASS'Y 1
E36‑1‑1 A2CA00000056
LCDBACKLIGHT,CCFL
1
E36‑1‑2 DFHM0290ZA
REFLECTION ANGLE
1
E36‑2 DFHR3612ZA LCDPWBSPACER 1
E36‑3 DFHR3647YA SPACERSHEET 2
E36‑4 DFHR3D92YA LCDBACKDAMPER 1
E36‑5
DFHR3570YA LCDBACKCUSHIONL
1
E36‑6 DFHR3571YA
LCDBACKCUSHIONS
2
E36‑7 DXHM0042ZA
SCREW
4
E36‑8 DFHR3648ZA
HOLDERSHEETB
2
E36‑9 DFHR3453YA
LCDBACKCUSHIONSIDE
3
