TIGHTENING TORQUES
9
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
TIGHTENING TORQUES
Body panels.
Cycle part.
Standard.
Front mudguard. 1 m.daN.
Handlebar cover. 0.1 m.daN.
Front shield panels. 0.1 m.daN.
Rear shield. 0.1 m.daN.
Bottom panel. 0.1 m.daN.
Footboard. 1 m.daN.
Saddle storage compartment. 1 m.daN.
Rear cover. 0.4 m.daN.
Grab handle. 2.2 m.daN.
Rear mudguard. 1 m.daN.
Front wheel spindle. 6.5 m.daN.
Rear wheel bolt. 9 m.daN.
Rear wheel spindle nut. 11 m.daN.
Linkrod to engine pivot. 4.5 m.daN.
Linkrod to swingarm. 4.5 m.daN.
Engine-upper linkrod pivot. 4.5 m.daN.
Shock absorber top mount. 2.5 m.daN.
Shock absorber bottom mount. 2.5 m.daN.
Front and rear frame mounting nut. 2.2 m.daN.
Exhaust to cylinder mounting nut. 1.5 m.daN.
Exhaust to casing mounting bolt. 2.2 m.daN.
Upper cone (in 2 operations). 3.8/2.3 m.daN.
Upper cone locknut. Hand tightened.
Steering locknut. 7.5 m.daN.
Front brake caliper. 3 m.daN.
Rear brake caliper. 2.2 m.daN.
Front brake disc. 1 m.daN.
Rear brake disc. 1 m.daN.
Handle bar. 3 m.daN.
Nut and bolt 5 mm diameter. 0.5 m.daN.
Nut and bolt 6 mm diameter. 1 m.daN.
Nut and bolt 8 mm diameter. 2.2 m.daN.
Nut and bolt 10 mm diameter. 3.5 m.daN.
Nut and bolt 12 mm diameter. 5.5 m.daN.
