WORKING ON THE ENGINE WITHOUT REMOVING THE ENGINE
23
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
- Remove one of the spring clips (2) using pliers
P/N 752000.
- Remove the gudgeon pin.
- Remove the piston.
- Remove the needle bearing race from the
connecting rod end.
When refitting the cylinder, we recommend locking the piston using the fork part number 756575
in order to facilitate assembly.
î
Removal of the water pump.
- Remove the exhaust.
- Disconnect the lower pump from the coolant
pump to drain the cooling system.
- Disconnect the upper hose.
- Remove the water pump.
2
756575
