ELECTRIC COMPONENTS
15
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
ELECTRIC COMPONENTS
Removal of the blinker unit.
Removal of the ignition module.
- Remove the front upper shield panel (see
procedure 1)
- Disconnect and remove the blinker unit (1).
- Disconnect and remove the ignition
module (2).
Removal of the headlight bulbs.
- Remove the bulbs (3).
The bulbs are held in the headlight by means of a plate which is locked by turning it to the right.
2
1
3
