PETROL CIRCUITS
19
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
î Removal of the carburettor.
- Remove the storage compartment (see
procedure 4).
- Remove the rear mudguard (1) 3 screws, 1 of
which is also used for the air filter).
- Disconnect the air pipe from tha air filter
housing (2).
- Remove the air filter (1 "click" collar).
- Disconnect the electric choke.
- Disconnect the separate lubrication hose (1).
- Remove the screw that secures the
carburettor chamber cap (2).
- Remove the carburettor and its cap and
needle valve.
- Disconnect the fuel supply hose (3) (1 "click"
collar).
1
2
3
1
2
