PEUGEOT Jet C-Tech User Manual

LOCATION OF COMPONENTS
11
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
LOCATION OF COMPONENTS
1. Oil pump control unit.
2. Battery.
3. Ignition sensor.
4. CDI unit.
5. Oil level indicator.
6. Oil pump.
7. HT coil.
8. Low oil level warning light.
9. STOP light.
10. Regulator.
11. Starter motor relay.
12. Flasher unit.
13. Horn.
14. Engine temperature sensor.
15. 7.5 A fuse.
16. Air pump.
7
10
6
11
2
5
4
12
3
1
15
16
8 9
13
14
1
2
V
-
2
5
A
-
U
P
P
E
R
L
E
V
E
L
L
O
W
E
R
L
E
V
E
L
STOP
NC
NC
