TIGHTENING TORQUES

Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles

TIGHTENING TORQUES

Engine part

Body panels

Spark plug 12 Nm

Filler cap 20 Nm

Screen 15 Nm

Cylinder head

Nut Ø6 mm

Screw Ø6 mm

20 Nm

12 Nm

Camshaft gear cover 10 Nm

Camshaft gear 20 Nm

Valve clearance covers 15 Nm

Automatic tensioner 10 Nm

Automatic tensioner plug 8 Nm

Chain tensioner 10 Nm

Inlet manifold 10 Nm

Crankcase 12 Nm

RH casing cover 12 Nm

Freewheel 90 Nm

Oil pump 10 Nm

Transmission cover 10 Nm

Relay box cover 22 Nm

Relay box drain plug 10 Nm

Starter motor 10 Nm

Rotor 55 Nm

Turbine 10 Nm

Stator 12 Nm

Engine speed sensor 12 Nm

Drive pulley 55 Nm

Driven pulley 55 Nm

Clutch plate and shoes 55 Nm

Front mudguard 8 to 10 Nm

Handlebar cover 1 to 2 Nm

Front shield panels 1 to 2 Nm

Rear shield 4 to 8 Nm

Bottom panel 1 to 2 Nm

Floor panel 4 to 8 Nm

Saddle storage compartment 4 to 8 Nm

Rear panels 1 to 2 Nm

Grab handle 20 to 25 Nm

Questions and Answers:

Need help?

Do you have a question about the PEUGEOT SpeedFight 3 and is the answer not in the manual?

PEUGEOT SpeedFight 3 Specifications

General

Displacement	49.9 cc
Cooling System	Air cooled
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Seat Height	800 mm
Dry Weight	97 kg
Width	700 mm
Top Speed	45 km/h
Transmission	Automatic
Engine Type	Single-cylinder, 2-stroke
Fuel Capacity	8 liters
