PEUGEOT SpeedFight 3 User Manual

CHARACTERISTICS
6
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
CHARACTERISTICS
Engine

Capacities
Speedfight 3
Type
4-stroke single-cylinder
Horizontal cylinder. 2 valves per cylinder with chain driven overhead
camshaft
Cooling
By a circulation of forced air by means of a turbine on the flywheel
magneto
Bore x stroke 37 x 46 mm
Cubic capacity 49.5 cc
Max. power output 2.8 kW at 8000 rpm
Max. torque rating 3.5 Nm at 6500 rpm
Compression 9.5 bars at 550 rpm
Fuel supply Carburettor KEIHIN NCV
Lubrication
Pressurised wet sump lubrication Trochoid pump driven by a gear set
from the crankshaft
Transmission By 2 variable pulleys and V-type belt
Clutch Centrifugal automatic
Exhaust With catalytic system and pulsair valve
Standards Euro 3
Starter motor By kick starter or electric starter
Spark plug
NGK CR6HSA
Electrode gap : 0.6 mm
Magneto flywheel 80 W
Crankcase
0.7 L SAE 5W40
Minimum grade : API SL/SJ
Relay box
0.1 L SAE 80W90
Minimum grade : API GL4
Fuel tank 8 l 95 or 98 lead-free

PEUGEOT SpeedFight 3 Specifications

General

Displacement	49.9 cc
Cooling System	Air cooled
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Seat Height	800 mm
Dry Weight	97 kg
Width	700 mm
Top Speed	45 km/h
Transmission	Automatic
Engine Type	Single-cylinder, 2-stroke
Fuel Capacity	8 liters
