PEUGEOT SpeedFight 3 User Manual

ELECTRICITY
47
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
ELECTRICITY
Ignition principle schematic/Carburetor heater
1. Ignition switch.
2. Battery.
3. CDI unit.
4. Spark plug socket.
5. Spark plug.
6. HT coil.
7. Carburetor heater.
8. Temperature control unit.
9. Automatic starter.
10.Magneto flywheel.
11.Revolution counter.
12.Regulator.
X 1000rpm
0
1
2
3
4
5
6
7
8
9
10
11
12
km/h
mph
km mi
TRIP
7,5A
OFF
ON
-
UPPER LEVEL
LOWER LEVEL
1 2
11
3
10
9
12
8 7
6
4
5
5
14
VE-NR
JN-BA
JN-NR
VE-BA
VE-NR
VE
RG
RG
NR
VE
VE
VE
VE
VE
VE
JN JN NR

PEUGEOT SpeedFight 3 Specifications

General

Displacement	49.9 cc
Cooling System	Air cooled
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Seat Height	800 mm
Dry Weight	97 kg
Width	700 mm
Top Speed	45 km/h
Transmission	Automatic
Engine Type	Single-cylinder, 2-stroke
Fuel Capacity	8 liters
