BODY PANELS

Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles

Removal of the rear cover assembly and

mudflap

Procedure 2.

- Remove the storage compartment. See:

Procedure 1 page 19.

- Remove the lower fairing by sliding it

towards the rear of the vehicle.

• 1 screw Ø6 mm.

- Remove the rear cover assembly

(10 screw).

• 6 plastic screws (A).

• 2 screw Ø5 mm (B).

• 2 screw Ø6 mm (C).

- Disconnect the taillight.

- Remove the splash guard.

• 4 plastic screws.

- Remove the taillight.

• 4 plastic screws.

- Separate the 2 fairings (1).

• 2 plastic screws.
