PEUGEOT SpeedFight 3 User Manual

SERVICE OPERATIONS
30
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
- When refitting, respect the way the rollers
are installed.
- Grease the moving flange bore lightly (high
temperature grease).
Checking the drive belt
- Measure the width of the belt (A).
Minimum width: 17.2 mm.
- Make sure the belt is not cracked.
A

PEUGEOT SpeedFight 3 Specifications

General

Displacement	49.9 cc
Cooling System	Air cooled
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Seat Height	800 mm
Dry Weight	97 kg
Width	700 mm
Top Speed	45 km/h
Transmission	Automatic
Engine Type	Single-cylinder, 2-stroke
Fuel Capacity	8 liters
