PEUGEOT SpeedFight 3 User Manual

FUEL SYSTEM
51
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
- Remove the needle stop (2).
- Remove the spring (3).
- Remove the needle (4).
Check that the membrane is in
good condition.
The height oif the needle is factory
set and cannot be modified.
Removal of the float, needle valve and
jets
- Remove the chamber (4 screw).
- Remove the float chamber and its O-ring.
Check the condition of the float
chamber O-ring.
- Loosen the float pin clamping screw (2).
- Remove the float (3), its pin (4) and the
needle valve (5).
2
3
4
5
2
3
4

PEUGEOT SpeedFight 3 Specifications

General

Displacement	49.9 cc
Cooling System	Air cooled
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Seat Height	800 mm
Dry Weight	97 kg
Width	700 mm
Top Speed	45 km/h
Transmission	Automatic
Engine Type	Single-cylinder, 2-stroke
Fuel Capacity	8 liters
