PIAGGIO MSS ZIP 100 4T User Manual

Steering column
Refitting
Lower and upper seating on the chassis
Lower and upper seating on the chassis
Removal
Washer and upper seating of upper bearing
After removing the upper seating, tilt the vehicle to
a side and take out the steering tube making sure
mudflaps have been removed and the calliper dis-
connected.
Lower and upper seating from the chassis
To remove the bearing seats from the chassis, use
the appropriate tool as shown in the figure.
N.B.
To remove the lower seating of the lower bearing just use a
screwdriver as a lever between the seating and the shell.
LOWER AND UPPER SEATING FROM THE CHASSIS
Titolo
Durata/Valore Testo Breve (< 4000 car.) Indirizzo Immagine
Lower and upper seating from
the chassis
Rear
MSS ZIP 100 4T Suspensions
SUSP - 133
